Chapter 5: Interconnection and Internal Cabling
5.4.5
Ethernet Site Link Cabling – MTS 4 Expansion Cabinet with Single
Site Controller
Table 48: Ethernet Site Link Cabling for MTS 4 Expansion Cabinet with Single Site Controller
In-
dex
Cable
Part Num-
ber
From Unit/ Con-
nection Name
To Unit/ Connec-
Notes
tion Name
5
1
3066544B
01
Base Radio 1 /
SC1
Site Controller1/
BR1
Ethernet link/ Grey cable
2
3066544B
02
Base Radio 2/
SC1
Site Controller1/
BR2
Ethernet link/ Black cable
3
3066544B
04
Base Radio 3/
SC1
Site Controller1/
BR3
Ethernet link/ Grey cable
4
3066544B
05
Base Radio 4/
SC1
Site Controller1/
BR4
Ethernet link/ Black cable
3066562B
Junction Panel/
RJ45 coupler
Bend Link breakout and in-
01
Link1
sert RJ45 coupler.
30015009
RJ45 coupler
Site Controller1/
Ethernet link/ Blue cable
001
RedIn
3066562B
01
Junction Panel/
Link2
RJ45 coupler
Bend Link breakout and in-
sert RJ45 coupler.
6
30015009
RJ45 coupler
XHUB Controller 1/
Ethernet link/ Beige cable
004
AUX1
Only in dual eNET configu-
ration
7
3066544B
12
Site Controller1/
Exp Cab
XHUB Controller1/
Prime Cab
Ethernet link
