Motorola DIMETRA X Core User Manual

3
6802800U74-AN
Chapter 5: Interconnection and Internal Cabling
In-
dex
Cable Part
Number
From Unit/ Connec-
tion Name
To Unit/ Connection
Name
Notes
1b Junction Panel/ DC2
Power Supply Unit 2/
DCIn Battery
N/A
2 3066553B01
Junction Panel/ AC
In 1
3 3066553B01
Junction Panel/ AC
In 2
Power Supply Unit 1/
ACIn
Power Supply Unit 2/
ACIn
With retaining clip
With retaining clip
4a
3066545B01
Power Supply Unit
Base Radio 1/ DCIn
Pins: 1, 2, 3, 8, 10,
and 11
Pins: 4, 5, 6, 9, 12,
4b 1/ DCOut Base Radio 2/ DCIn
and 13
4c Y Splitter Pins: 7 and 14
Site Controller 1/
Power 1
4d 3066574B01 Y Splitter
5a
3066545B01
Power Supply Unit
Site Controller 2/
Power 2
Base Radio 3/ DCIn
Pins: 1, 2, 3, 8, 10,
and 11
Pins: 4, 5, 6, 9, 12,
5b 2/ DCOut Base Radio 4/ DCIn
and 13
5c Y Splitter Pins: 7, 14
Site Controller 1/
Power 2
5d 3066574B01 Splitter
6 3066556B02
Junction Panel/ Bat-
Temp. 1
7 3066556B02
Junction Panel/ Bat-
Temp. 2
Site Controller 2/
Power 1
Power Supply Unit 1/
BatteryTemp.Sens.
Power Supply Unit 2/
BatteryTemp.Sens.
N/A
N/A
8 3066557B01
Power Supply Unit
1/ ATCC DC Out
Power Supply Unit
ATCC 1/ DC In
Only for configura-
tion with ATCC
Only for configura-
9 3066557B01
2/ ATCC DC Out
ATCC 2/ DC In
tion with two
ATCCs
10 306659B01
ATCC 1/Inside
ATCC Interconnec-
tion
ATCC 2/Inside ATCC
Interconnection
Only for configura-
tion with two
ATCCs
