VJ-1624X/1624WX/1924WX OPERATION MANUAL 4 Handling the printer
4.4 Operating from Operation panel 195
4.4.5.2 Settings that can be changed or confirmed while printing
• When you change a setting during operation, be sure to select "Backup" to save the setting that you
changed.
If the printer returns to Normal without "Backup" being selected, the changed setting is not saved.
• Check the following before using the Job status items
• The values displayed in the Job status items are rough indications.They do not guarantee the
strict accuracy.
• If the length information is not included in the print data, "0" is displayed for all items.
• You can check the "remaining print" and "remaining time" in the way described in
4.4.8 Normal Display while Printing
• To check the information about the printed data, refer to the following.
5.8 Job Status Menu
Setup item Setting Description Reference
Temperature
(VJ-1624X only)
Pre Checks the current temperature of Pre-heater. —
Platen Checks the current temperature of Platen
heater.
Dryer Checks the current temperature of Dryer.
Pre-heater
(VJ-1624X only)
Off / 30ºC to 50ºC Changes the temperature of Pre-heater.
5.1.1.1.4 Pre-heater
menu (VJ-1624X only)
Platen heater
(VJ-1624X only)
Off / 30ºC to 50ºC Changes the temperature of Platen heater.
5.1.1.1.5 Platen
Heater menu (VJ-1624X
only)
Dryer
(VJ-1624X only)
Off / 30ºC to 50ºC Changes the temperature of Dryer.
5.1.1.1.6 Dryer
menu (VJ-1624X only)
PF Adjust -5.00% to 0.00 to 5.00% Change the feed adjustment value.
5.1.1.1.3 Media
feed compensation
Backup — • [Enter] key: Save the changed setting. —
Job Status ToDoLength Checks the length of data currently printing
(media feeding direction).
Done Checks the already printed length of data
currently printing.
Remain Checks the remaining length of data currently
printing.
Remain Time The remaining time to complete the printing
will be displayed.
— — • [Cancel] key: The printer returns to
Normal.
To Next Page
