8 Appendix VJ-1624X/1624WX/1924WX OPERATION MANUAL
344 8.1 Product specifications
8.1 Product specifications
8.1.1 Printer specifications
Items Specification
Model name VJ-1624X
VJ-1624WX
VJ-1924WX
Printing method On-demand piezo drive system
Drive system Firmware servo/DC motor drive
Media feed system Multipoint pressurizing grid roller system
Media fixing system Pressurization roller down system by manual lever
Media feed/ejection Rear feed/Front ejection
Roll media outer diameter 150mm or less
Roll media weight 30kg or less
Maximum media width <VJ-1624X/1624W>
1,625mm
<VJ-1924WX>
1,900mm
Minimum media width 900mm
Maximum media thickness VJ-1624X: 0.3mm (when the head height is Low)/1.3mm (when the head
height is High)
VJ-1624WX/1924WX: 0.3 mm (when the head height is Low)/1.3 mm (when
the head height is Mid)/2.8 mm (when the head height is High)
Maximum printable media width <VJ-1624X/1624W>
1,615mm
<VJ-1924WX>
1,900mm
Print margin Top: 5 mm (15 mm after media initialization or after winding the media
manually, 40 mm when media initialization front edge detection is ON or after
cutting the media), Bottom: 5 mm (102 mm at the roll media end), Left: 5 mm
to 25 mm, Right: 5 mm to 25 mm.
Media cut system Horizontal automatic cut system/manual cut system
Head height adjustment VJ-1624X: Two-level adjustment of Low and High
VJ-1624WX/1924WX: Three-level adjustment of Low, Mid, and High
CPU 64-bit RISC CPU
Memory <VJ-1624X/VJ-1624WX>
128MB
<VJ-1924WX>
256MB
Command MH-RTL (RTL-PASS)
Interface Network interface (Ethernet IEEE 802.3)
