VJ-1624X/1624WX/1924WX OPERATION MANUAL 4 Handling the printer
4.4 Operating from Operation panel 191
4.4.3 Cutting media
This section explains how to cut media.
If Media ejection mode is set to Auto Cut, the printer cuts the media automatically after printing.
5.1.6 Output Mode menu
If you press the [Cutting] key on Operation panel more than two seconds while Operation panel is
Normal, you can cut the media at the desired position.
Follow the procedure below to cut the roll media.
1. Confirm that Operation panel is Normal.
2. Press the [Cutting] key on Operation panel for more than 2 seconds.
• The printer feeds the roll media to the length of the margin and cuts the media.
• When loading the new roll media, cut the front edge of the media if it is not straight.
• The cutter is a consumable component.
Replace it periodically.
5.1.4 Media Initial menu
• When the the media detection is set to "Off", the media cannot be cut automatically.
5.1.4 Media Initial menu
