Before using VJ-1624X/1624WX/1924WX OPERATION MANUAL
82 3.4 Loading media
3.4.2 Setting Roll Media
This section explains how to set the roll media.
Follow the procedure below to set the roll media.
1. Turn the printer ON.
• Do not operate Media loading lever during initial operation.
Print head may touch Pressurizing roller and cause a malfunction.
• The printer starts the initializing operation.
• "Media End" is displayed on Operation panel.
2. Raise Media loading lever.
• "Lever Up" is displayed on Operation panel.
No. Name
1 Media loading lever
To Next Page
