VJ-1624X/1624WX/1924WX OPERATION MANUAL Before using
3.4 Loading media 83
3. Open Front cover.
4. Set the roll media to Media feed slot.
NOTE
If the end of the roll media is not wound tightly, wind it tightly again, and then load it.
No. Name
1 Front cover
No. Name
1 Roll media
2Media feed slot
1
12
