VJ-1624X/1624WX/1924WX OPERATION MANUAL Before using
3.6 Print quality adjustment 151
3.6.2.2.2 Rough Pattern A to F
Print one adjustment pattern from A to F and register the set value.
The following describes how to adjust pattern A only.
1. Display the Custom Adjust Print menu on Operation panel in the same way as Step 2 of
3.6.2.1 Custom confirmation pattern.
2. Press the [+] key or [-] key on Operation panel to select “Adj.3: RoughPattern A”.
3. Press the [Enter] key on Operation panel.
• “Warming Up Skip ->E” is displayed on Operation panel.
• While “Warming Up” is displayed, do not touch Platen and Media guide.
They become very hot and you could burn yourself.
• 4.4.7 Starting printing during warming up
• A rough adjust print pattern is printed.
(Starts printing after warming up is complete.)
To Next Page
