MUTOH ValueJet VJ-1624X User Manual

Before using VJ-1624X/1624WX/1924WX OPERATION MANUAL
152 3.6 Print quality adjustment
<For VJ-1624X>
<For VJ-1624WX/1924WX>
• For the Adjust print pattern, the same patterns will be printed repeatedly on both sides and center
of the media.
4. Check the print results on both sides and center of the media and select the number that looks most
aligned between 1 and 11 (1 and 21 for VJ-1624WX/1924WX).
• “9” is selected in the next printing sample.
1234567891011
Bi dir
Low H.Height
normal speed
large drop family
Pattern name
Print information
123456789101112131415161718192021
Bi dir
Low H.Height
normal speed
large drop family
Pattern name
Print information
8910
Not adequate Adequate
Not adequate
