VJ-1624X/1624WX/1924WX OPERATION MANUAL 4 Handling the printer
4.2 Media 169
4.2.5.1 When setting the head height to Mid (VJ-1624WX/1924WX only)
Do not open Front cover and change the head height during printing.
If the head height is changed, the alignment will be changed and high print quality will not be
guaranteed.
1. Open Front cover.
2. Change the head height by moving Head height adjustment lever (orange).
• High lamp on Operation panel lights up in green.
• Low lamp on Operation panel lights up in green.
No. Name
1 Front cover
No. Name
1 Head height adjustment lever
To Next Page
