Before using VJ-1624X/1624WX/1924WX OPERATION MANUAL
158 3.6 Print quality adjustment
3.6.2.3.2 Fine Pattern A to F
Print one adjustment pattern from A to F and register the set value.
The following describes how to adjust pattern A only.
1. Display the Custom Adjust Print menu on Operation panel in the same way as Step 2 of
3.6.2.1 Custom confirmation pattern.
2. Press the [+] key or [-] key on Operation panel to select “Adj.10: Fine PatternA”.
3. Press the [Enter] key on Operation panel.
• For VJ-1624X, “Warming Up Skip ->E” is displayed on Operation panel.
(This is not displayed for VJ-1624WX/1924WX since it does not perform warming up.)
• While “Warming Up” is displayed, do not touch Platen and Media guide.
They become very hot and you could burn yourself.
• You can start printing during warming up.
4.4.7 Starting printing during warming up (VJ-1624X only)
