VJ-1624X/1624WX/1924WX OPERATION MANUAL Before using
3.6 Print quality adjustment 131
3.6.1.2 Standard rough adjustment pattern
Perform rough adjustment when the degree of misalignment is big.
Print rough adjustment pattern and register the set values.
1. Display the Standard Adjust Print menu on Operation panel in the same way as Step 2 of
3.6.1.1 Standard confirmation pattern.
2. Press the [+] key or [-] key on Operation panel to select "Adj.2: Rough Pattern".
3. Press the [Enter] key on Operation panel.
• For VJ-1624X, "Warming Up Skip ->E" is displayed on Operation panel.
(This is not displayed for VJ-1624WX/1924WX since it does not perform warming up.)
• While "Warming Up" is displayed, do not touch Platen and Media guide. They
become very hot and you could burn yourself.
• You can start printing during warming up.
4.4.7 Starting printing during warming up (VJ-1624X only)
To Next Page
