CHAPTER 3 SYSTEM DATA PROGRAMMING
– 202 – NWA-008853-001 Rev.3.0
97ch3003.fm
SMDR with AP00 Programming (PN-AP00-B/PN-AP00-D with MRCA
program) (1)
[Series 3300 software required]
To send a billing information from local offices to SMDR of center office, do the following programming.
To send a billing information of center office to SMDR terminal via RS-232C interface, do the program-
ming of SMDR with AP00 programming (PN-AP00-B/PN-AP00-D with MRCA program). For details of
the programming, refer to Station Message Detail Recording (SMDR) of Feature Programming Manual.
DESCRIPTION DATA
Assign the system clock data. (1)
(2)
0: Calendar Year
2000-2099 (Ex. 2001)
(1)
(2)
1: Date
MM DD WW
MM : 01-12 (Month)
DD : 01-31 (Date)
WW: 00 (Sun)
01 (Mon)
02 (Tue)
03 (Wed)
04 (Thu)
05 (Fri)
06 (Sat)
(1)
(2)
2: Time
HH MM SS
HH : 00-23 (Hour)
MM: 00-59 (Minute)
SS : 00-59 (Second)
START
CM02
A
JULY/01/2006
CENTRALIZED BILLING-CCIS
