• When no release signal arrives on the IC trunk.
DESCRIPTION DATA
Provide the DIT-Outside feature. (In case of no
release signal on IC trunk.)
(1)
(2)
324: DIT-Outside
0: Allow
(When both answer and release signal ap-
pear on the OG trunk)
Assign the data for terminating system in Day
Mode, Night Mode, Mode A and Mode B for
the trunk, respectively.
•
•
•
•
(1)
(2)
Y=02 Day Mode
Y=03 Night Mode
Y=40 Mode A
Y=41 Mode B
000-255: Trunk No.
04: Direct-In Termination
Assign the Abbreviated Code for System
Speed Dialing to terminate to the other system
via CCIS by DIT in Day Mode and Night
Mode, Mode A and Mode B respectively.
•
•
•
•
(1)
(2)
Y=04 Day Mode
Y=05 Night Mode
Y=42 Mode A
Y=43 Mode B
000-255: Trunk No.
CXX
XX: 00-31 (Abbreviated Code for System
Speed Dialing Assigned by
CM71>66)
Assign trunk route data to the trunk route num-
ber (for IC route).
•
(1)
(2)
Y=02 IC/BW
00-63: Trunk Route No.
1 : Incoming Trunk
3 : Bothway Trunk
•
(1)
(2)
Y=05
Release Signal from Distant Office
00-63: Trunk Route No.
0: Not arrive
•
(1)
(2)
Y=09 Incoming Connection Signaling
00-63: Trunk Route No.
15 : Ring Down
START
CM08
CM30
CM35
A
DIRECT-IN TERMINATION-CCIS
