NEC SL1100 - Page 211

NEC SL1100 Issue 6.0
Networking Manual 9 - 77
10-12-09 CPU Network Setup – IP Address
Assign the IP Address for the
VoIPDB. If a VoIPDB is installed in
the system it is recommended to
set PRG 10-12-01 to 0.0.0.0 and
all connections to the system will
be made through the VoIPDB.
0.0.0.0 ~
126.255.255.254
128.0.0.1 ~
191.255.255.254
192.0.0.1 ~
223.255.255.254
(default = 172.16.0.10)

10-12-10 CPU Network Setup – Subnet
Mask
Define the Media Gateway Subnet
Mask Address.
128.0.0.0
192.0.0.0
224.0.0.0
240.0.0.0
248.0.0.0
252.0.0.0
254.0.0.0
255.0.0.0
255.128.0.0
255.192.0.0
255.224.0.0
255.240.0.0
255.248.0.0
255.252.0.0
255.254.0.0
255.255.0.0
255.255.128.0
255.255.192.0
255.255.224.0
255.255.240.0
255.255.248.0
255.255.252.0
255.255.254.0
255.255.255.0
255.255.255.128
255.255.255.192
255.255.255.224
255.255.255.240
255.255.255.248
255.255.255.252
255.255.255.254
255.255.255.255
(default = 255.255.0.0)

10-46-06 Register Port
Assign the port number to which
the SIP messages are sent to on
the
VoIPDB. This same port
number must be assigned in the
SIP Multiline terminals. If this
command is changed, it requires a
CPU reset.
0~65535 5080

Program
Number
Program Name Description/Comments Assigned Data
Level
1 2 3
