Issue 6.0 NEC SL1100
9 - 78 IP Multiline Station (SIP)
10-46-13 Subscribe Session Port 0~65535 5081

10-46-14 NAT Mode Turns On/Off the NAT mode of the
system.
0 = Off
1 = On
Default = Off

15-05-45 NAT Plug&Play Effective when PRG 10-46-14 is
set to NAT Mode. Select sending
RTP port number to remote router,
use from negotiation result (0) or
received RTP packet (1).
0 = Off
1 = On
Default = Off

15-05-47 IP Telephone Terminal Basic
Data Setup - Registration Expire
Timer for NAT (V3.5 added)
On a per station basis, this setting
defines the SIP registration expiry
timer. This setting only applies to
DR700 stations connected via
NAPT. If this value is set to 0, for a
NAPT terminal, the value in PRG
84-23-01 is applied.
0 = Disable
60 ~ 65535 (sec)
Default = 180

15-05-48 IP Telephone Terminal Basic
Data Setup - Subscriber Expire
Timer for NAPT (V3.5 Added)
On a per station basis, this setting
defines the SIP subscribe expiry
timer. This setting only applies to
DR700 stations connected via
NAPT. If this value is set to 0, for a
NAPT terminal, the value in PRG
84-23-02 is applied.
0 = Disable
60 ~ 65535 (sec)
Default = 180

84-26-01 VoIPDB Basic Setup (DSP)– IP
Address
Assign the IP address for the VoIP
Gateway.
Default = 172.16.0.20

84-26-02 VoIPDB Basic Setup (DSP)– RTP
Port Number
Assign the RTP port number to be
used for the DSP on the VoIPDB.
VoIP GW =
10020~10083

84-26-03 VoIPDB Basic Setup (DSP)–
RTCP Port Number (RTP Port
Number + 1)
Define the port number for RTCP
to use for each DSP.
VoIP GW = 10021

Program
Number
Program Name Description/Comments Assigned Data
Level
1 2 3
