NEC SL1100 - Page 227

NEC SL1100 Issue 6.0
Networking Manual 10 - 15
10-58-02
Network Address –
Subnet Mask
If there are other
networks connected to
system that are not to be
routed through NAPT
translations, then these
networks must be
identified in PRG 10-58.
Use this PRG to assign
the subnet mask for the IP
Address entered in PRG
10-58-01.
Assign a valid subnet mask.
default is 0.0.0.0
X
15-05-16
IP Telephone
Terminal Basic Data
Setup – Password
Assign the authentication
password for SIP single
line telephones.
Up to 24 characters
Default not assigned
X
15-05-45
IP Telephone
Terminal Basic Data
Setup- NAT Plug &
Play
Per IP Single line
telephone, enable NAT
Plug and Play so that port
forwarding is NOT
required in the router the
IP single line telephone
resides behind. Effective
only when PRG 10-46-14
is set to 1 = Enable.
0 = No (Disable)
1 = Yes (Enable)
default is 1
X
15-05-47
IP Telephone
Terminal Basic Data
Setup –
Registration Expire
Timer for NAT
On a per station basis,
this setting defines the
SIP registration expiry
timer. If this value is set to
0, for the terminal, the
value in PRG 84-23-01 is
applied.
Note – This option is only
available in system
software 3.50 or higher.
0 = User Timer in Program
84-23-01 60~65535(sec)
default is 180 seconds
X
15-05-48
IP Telephone
Terminal Basic Data
Setup – Subscribe
Expire Timer for
NAT
On a per station basis,
this setting defines the
SIP subscribe expiry
timer. If this value is set to
0, for the terminal, the
value in PRG 84-23-02 is
applied.
Note – This option is only
available in system
software 3.50 or higher.
0 = User Timer in Program
84-23-01 60~65535(sec)
default is 180 seconds
X
Program
Number
Program Name
Description/
Comments
Assigned Data 1 2 3
