Netafim nmc-pro - LCD & Keyboard Replacement; NMC-PRO: Old LCD & Keyboard Replacement

NMC-PRO Installation Manual
145Page
REPLACEMENT AND ADDITIONAL INSTALLATIONS
16.5 LCD & Keyboard Replacement
If LCD or keyboards are no longer in working condition first recognize if your LCD or keyboard is an OLD or NEW
version.
16.5.1 NMC-PRO: Old LCD & Keyboard Replacement
Fluorescen
High Voltage
Cable
Screws
(x4)
Screws (x6)
Wire
Old LCD SAP# : 74340-007600
Old Keyboard SAP#: 74340-007700
Sensor
Type
No High
Voltage
Fluorescent
High Voltage
OLD
Old LCD SAP# : 74340-007600
Old Keyboard SAP#: 74340-007700
Refer to the next page for the old version.
Refer to the following page for the new version.
LED Wires
NEW
New LCD - SAP #: 74340-004920
New Keyboard - SAP#: 74340-003300
