NMC-PRO Installation Manual
94Page
TEST MENU
9.3 Analog Input
Analog inputs will show values from 0 to 1023.
Sensor type Description
pH sensor
pH = 0 – A/D = 205
pH = 7.0 – A/D = 615
pH = 14.0 – A/D = 1023
EC sensor
EC = 0 – A/D = 205
EC = 2.0 – A/D = 370
EC = 10.0 – A/D = 1024
Humidity sensor
RH% = 0 – A/D = 0
RH% = 50 – A/D = 308
RH% = 100 – A/D = 620
Temp sensor
T°C = 0 – A/D = 768
T°C = 25 – A/D = 489
T°C = 50 – A/D = 250
9.4 Temperature
This table shows the current temperature sensor readings in degrees (Celsius or Fahrenheit depending on the setup
in the screen).
