NMC-PRO Installation Manual
157Page
SENSOR INSTALLATION AND DEFINITION
17.5.2.2 Radiation Sensor Configuration - Option B- Davis
17.6 Pressure Transducer Connection
Sensor type
Jumper positioning
Temperature sensor (30kΩ)
Temp
Pressure inlet, Pressure outlet
0-5V
Pressure inlet, Pressure outlet
4-20mA
Pressure inlet – IN 8 :
Pressure outlet– IN 9 :
P in - COM
P in - Input
P out - COM
P out - Input
Filter Station
Cable type
3x0.5mm
2
(20AWG) Shielded
6
7
8
9
10
MENU
Enter Radiation Factor at
fixed value of 1.67
ENTER to show options
Davis and press ENTER
MENU
1
2
3
4
5
