5.3. WGBizPark
A business park intends to provide communication services to the companies it hosts. Each
company will have its own internal LAN which will be inaccessible from other companies‟ internal
LANs. The companies will also have a VPN service to allow authorized users to access the internal
LAN from the outside.
The Access Points to be used are capable of broadcasting several SSIDs and of VLAN tagging the
packets of each different SSID.
Each company will have its own IEEE 802.1Q VLAN, for separating its traffic from other company‟s
traffic.
In this way, it will be possible to configure an SSID per company and connect it to the company‟s
internal network VLAN. Finally, one of the SSIDs will be used for visitors and will have its own VLAN
tag.
Companies may also install their own internal servers and port forwarding to be enabled at the
WGS5000.
5.3.1. Configuration example
Figure 100: WGBizPark – Configuration Example
