Electrical System
11-13
Part 1079832_04
E 2015 Nordson Corporation
250
240
230
220
210
200
190
180
170
160
150
140
130
RESISTANCE IN OHMS
310
300
290
280
270
260
250
240
230
350
340
330
320
RESISTANCE IN OHMS
TEMPERATURE
TEMPERATURE
16 _C 23 _C 30 _C 37 _C 44 _C 52 _ C 59 _C 66 _C 73 _C 81 _C 88 _C 95 _ C 102 _C 109 _C 117 _C
60 _F 73 _F 86 _F 99 _F 112 _F 125 _F 138 _F 151 _F 164 _F 177 _F 190 _F 203 _F 216 _F 229 _F 242 _F
268 _F 281 _F 294 _F 307 _F 320 _F 333 _F 346 _F 359 _F 372 _F 411 _F 424 _F 437 _F 450 _F385 _F 398 _F
131 _C 138 _C 146 _C 153
_C 160 _C 167 _C 174 _C 182 _C 189 _C 196 _C 203 _C 211 _C 218 _C 225 _C 232 _C
Figure 11-11 Nickel RTD resistance vs. RTD temperature
