Electrical System
11-14
Part 1079832_04
E 2015 Nordson Corporation
Checking an RTD (contd)
205
200
195
190
185
180
175
170
165
160
155
150
145
140
135
130
125
120
115
110
105
100
32 68 104 140 176 212 248 284 320 356 392 428 464
0 20 40 60 80 100 120 140 160 180 200 220 240
Temperature in F
o
Resistance in ohms (platinum RTD)
Temperature in C
o
Figure 11-12 Platinum RTD resistance vs. RTD temperature
