NORMARC 7013 - Table 6-5 Monitor 1 Window; Table 6-6 Front Panel Window (Displays Tx2 to Air)

OPERATING MANUAL
6-14
21833-3.4
NORMARC 7013
INSTRUMENT LANDING SYSTEM
Periodic maintenance CAT I and II ©1999 Navia Aviation AS
Table 6-5 Monitor 1 window
(Not for recordings, make a "print screen copy")
Table 6-6 Front panel window (Displays Tx2 to air)
MON1 MON2
CL DDM % 0.0 0.0
SDM % 40.0 40.0
RF V 3.0 3.0
DS DDM % 0.0 0.0
SDM % 40.0 40.0
RF V 3.0 3.0
NF DDM % 0.0 0.0
SDM % 40.0 40.0
RF V 3.0 3.0
CLR DDM % 0.0 0.0
SDM % 40.0 40.0
RF V 3.0 3.0
DF kHz 10.0 10.0
CL IDENT OK OK
CLR IDENT OK OK
Self test OK OK
DC-loop OK OK
Tx1 Tx2
O
O
Coax Pos O
MAIN O
