©1999 Navia Aviation AS 21833-3.4 Main cabinet
OPERATING MANUALNORMARC 7013
INSTRUMENT LANDING SYSTEM
3-1
PART II OPERATION
3 Main cabinet
3.1 Power on/off
The power ON/OFF switches are located on front of the main cabinet. Adjacent to the
switches are GND sockets for connecting wrist strap to ensure ESD-protected environment
when performing maintenance operations.
Figure 3-1 Power ON/OFF and GND Sockets Location
1 1
POWER ON/OFFGND SOCKETS
HBK548-1
