B.6.7 Power supply 1 and 2 (PS 1227)
The measurements listed here are displayed in the DC SUPPLIES maintenance window in
the RMM software.
B.6.8 External power
The measurements listed here are displayed in the DC SUPPLIES maintenance window in
the RMM software.
B.6.9 User defined inputs
No default settings are defined for these parameters.
B.7 Maintenance delay configuration
The factory default maintenance delays are as follows:
GEN delay: 20 seconds
EXT delay: 50 seconds
B.8 Morse code configuration
The factory default Morse code are “TST”.
B.9 Typical TX Adjustments values
Typical TX adjustment values lists typical values entered in the RMM software (menu item ILS
| TX settings | TX adjustments) entered in the RMM software for LLZ and GP equipment.
Measurement Warn. limit Description
V15N LEVEL -16.8/-13.8
(V)
Measurement of -15 V output voltage (Volt).
V5P LEVEL 4.6/5.9 (V) Measurement of +5 V output voltage (Volt).
V8P5P LEVEL 8.2/9.4 (V) Measurement of +8.5 V output voltage
(Volt).
V15P LEVEL 13.8/16.8 (V) Measurement of +15 V output voltage
(Volt).
Measurement Warn. limit Description
BATTERY V27P LEVEL 23/28 (V) Measurement of 27 V battery supply volt-
age.
BATTERY CURRENT -1/10 (A)
POWER CURRENT -1/20 (A)
CHARGER 1 STATUS ON Battery charger 1 status input.
CHARGER 2 STATUS ON Battery charger 2 status input.
Measurement Description
USER_DIG0 - 7 8 user definable digital inputs/output.
TEMP_OUTDOOR Analog input for outdoor temperature sensor.
TEMP_INDOOR Analog input for indoor temperature sensor.
AC_LEVEL Analog input AC power level measurement.
ANA_CH1 - 3 3 user definable analog inputs.
