NORMARC 7013 - Table 6-3 Monitor 1 Window; Table 6-4 Front Panel Window (Displays Tx1 to Air)

©1999 Navia Aviation AS 21833-3.4 Periodic maintenance CAT I and II
OPERATING MANUALNORMARC 7013
INSTRUMENT LANDING SYSTEM
6-13
Table 6-3 Monitor 1 window
(Not for recordings, make a "print screen copy")
Table 6-4 Front panel window (displays Tx1 to air)
MON1 MON2
CL DDM % 0.0 0.0
SDM % 40.0 40.0
RF V 3.0 3.0
DS DDM % 0.0 0.0
SDM % 40.0 40.0
RF V 3.0 3.0
NF DDM % 0.0 0.0
SDM % 40.0 40.0
RF V 3.0 3.0
CLR DDM % 0.0 0.0
SDM % 40.0 40.0
RF V 3.0 3.0
DF kHz 10.0 10.0
CL IDENT OK OK
CLR IDENT OK OK
Self test OK OK
DC-loop OK OK
Tx1 Tx2
O
O
O Coax Pos
O Main
