B.6.1 LF generator 1 and 2 (LF 1223)
B.6.2 TX 1 and 2, Course and Clearance
B.6.3 RF frontends for monitor 1, 2 and standby monitor (MF 1211/1219)
Measurement Warn. limit. Description
COU LEVEL 90 HIGH Course line 90 Hz output level ok/not ok.
COU LEVEL 150 HIGH Course line 150 Hz output level ok/not ok.
COU LEVEL DC HIGH Course line DC output level ok/not ok.
CLR LEVEL 90
HIGH
Clearance 90 Hz output level ok/not ok.
CLR LEVEL 150 HIGH Clearance 150 Hz output level ok/not ok.
CLR LEVEL DC HIGH Clearance DC output level ok/not ok.
V15P OK HIGH +15 V supply voltage ok/not ok.
V15N OK LOW -15 V supply voltage ok/not ok.
Measurement Warn. limit. Description
PA V27P LEVEL 24/27 (V) +27 V voltage measurement (Volt).
CSB POWER LEVEL 12/17 (W) CSB output power measurement (Watt).
SBO POWER LEVEL 0.2/0.8 (W) SBO power measurement (Watt).
PH CORR PEAK LEVEL 1/13 Phase correlation peak level measurement.
May indicate that the transmitter is working
outside its dynamic range.
PS1/2 COU/CLR I90/I150 -0.5/1.5 (A) Current consumption in 90/150 Hz amplifi-
ers (Ampere). The TX1 currents is meas-
ured on PS1, the TX2 currents on PS2.
These measurements are listed in the DC
Supplies maintenance parameter window in
the RMM software, but are associated with
the LPA/GPA modules in the automatic
diagnostic functions.
Measurement Warn. limit Description
CL RF LEVEL HIGH
Detects low Course Line RF level.
CL BASEBAND HIGH Detects low Course Line baseband level.
DS RF LEVEL HIGH Detects low Course Line RF level.
DS BASEBAND HIGH Detects low Course Line baseband level.
NF RF LEVEL HIGH Detects low Near Field RF level.
NF BASEBAND HIGH Detects low Near Field baseband level.
CLR RF LEVEL HIGH Detects low Clearance RF level.
CLR BASEBAND HIGH Detects low Clearance baseband level.
