The clearance transmitter frequency is set with straps in the J102 strap block. The configured
clearance frequency is the channel frequency - 5 kHz.
Table B-7 OS1221A Clearance frequency settings for 2-freq. LLZ
Ch. freq.
(MHz)
A0 A1 A2 A3 A4 A5 N0 N1 N2 N3 N4 N5 N6 N7 N8 N9
108.1 X X X X X X X X
108.15 X X X X X X X
108.3 X X X X X X X X
108.35 X X X X X X X X X
108.5 X X X X X X X X X
108.55 X X X X X X X X
108.7 X X X X X X X
108.75 X X X X X X X
108.9 X X X X X X X X X
108.95 X X X X X X X X
109.1 X X X X X X X
109.15 X X X X X X X X X
109.3 X X X X X X X X
109.35 X X X X X X X
109.5 X X X X X X X X
109.55 X X X X X X X X
109.7 X X X X X X X
109.75 X X X X X X
109.9 X X X X X X
109.95 X X X X X X X
110.1 X X X X X X X X X X
110.15 X X X X X X X X X
110.3 X X X X X X X X
110.35 X X X X X X X X
110.5 X X X X X X X X
110.55 X X X X X X X
110.7 X X X X X X
110.75 X X X X X X X X X
110.9 X X X X X X X X
110.95 X X X X X X X
111.1 X X X X X X X
111.15 X X X X X X X
111.3 X X X X X X
111.35 X X X X X
111.5 X X X X X X X
111.55 X X X X X X X X
111.7 X X X X X X X X
111.75 X X X X X X X
111.9 X X X X X X
111.95 X X X X X X
