Nortel BayStack 350 Series - Spanning Tree Port Configuration

Using the BayStack 350 Series 10/100 Autosense Switch
3-62
893-00992-E
Figure 3-27. Spanning Tree Configuration Menu screen
Table 3-26 describes the Spanning Tree Configuration Menu options.
Table 3-26. Spanning Tree Configuration Menu Options
Option Description
Spanning Tree Port Configuration...
Displays the Spanning Tree Port Configuration screen (see
“
Spanning Tree Port Configuration” on page 3-63).
Display Spanning Tree Switch Settings
Displays the Spanning Tree Switch Settings screen (see “
Display
Spanning Tree Switch Settings” on page 3-65).
Return to Main Menu
Exits the Spanning Tree Configuration Menu and displays the
main menu.
Spanning Tree Configuration Menu
Spanning Tree Port Configuration...
Display Spanning Tree Switch Settings
Return to Main Menu
Use arrow keys to highlight option, press <Return> or <Enter> to select option.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
