Using the BayStack 350 Series 10/100 Autosense Switch
3-32
893-00992-E
Accelerator Keys for Repetitive Tasks
You can use accelerator keys to help speed up repetitive tasks. For example,
suppose you want to modify one of the port number lists shown in Figure 3-12
on
page 3-31
.
Adding A New Port to an Existing Port Number List:
In the example shown in Figure 3-12, entry 6 shows the Allowed Source Ports (s)
field values as:
1, 3, 5, 9, 12, 16
If you want to add another port (port 14) to the existing port number list, you
would normally have to highlight the field and then type another port list,
including the new port number: 1, 3, 5, 9, 12, 14, 16 [Return].
This works but is quite time-consuming.
Table 3-11. MAC Address Security Table Screen Fields
Field Description
MAC Address
Allows you to specify up to 98 MAC addresses that are authorized to access
the switch. You can specify the ports that each MAC address is allowed to
access using the Allowed Source Ports field (see next field description). The
specified MAC address does not take effect until the Allowed Source Port field
is set to some value. You can clear an existing MAC address field by entering
zero (0) in the field and pressing [Enter].
Default -----(no address assigned)
Range A range of 6 Hex Octets, separated by dashes (multicast
1
and
broadcast addresses are not allowed).
1
Multicast address -- Note that the first octet of any Multicast address will always be an odd number.
Allowed Source Ports
Allows you to specify the ports that each MAC address is allowed to access.
The options for port access include none, all, and ports that are specified in a
list (for example, 1-4, 6, 9, etc.).
Default - (Blank field)
Range A port number list (for example, 1-4, 6, 9, etc.), NONE, ALL
