Using the Console Interface
893-00992-E
3-65
Display Spanning Tree Switch Settings
The Spanning Tree Switch Settings screen (Figure 3-29) allows you to view
spanning tree parameter settings for the BayStack 350 switch.
Choose Display Spanning Tree Switch Settings (or press d) from the Spanning
Tree Configuration Menu to open the Spanning Tree Switch Settings screen.
Figure 3-29. Spanning Tree Switch Settings screen
Spanning Tree Switch Settings
Bridge Priority: 8000
Designated Root: 80000000A2EFD380
Root Port: 0
Root Path Cost: 0
Hello Time: 2 seconds
Maximum Age Time: 20 seconds
Forward Delay: 15 seconds
Bridge Hello Time: 2 seconds
Bridge Maximum Age Time: 20 seconds
Bridge Forward Delay: 15 seconds
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
