Trunk Utilization
The Trunk Utilization screen (Figure 3-20
and Figure 3-21) allows you to monitor
the percentage of bandwidth used by configured trunk members. You can choose
the type of traffic to monitor.
Figure 3-20
shows an example of bandwidth utilization rates for the trunk member
ports configured in inter-switch trunks I1, I2, I3, and I4. To display utilization for
server trunks S1 to S4, press [Ctrl]+N.
Figure 3-21
shows an example of bandwidth utilization rates for the trunk member
ports configured in server trunk S1.
Choose Trunk Utilization (or press u) from the MultiLink Trunk Configuration
Menu screen to open the Trunk Utilization screen.
Figure 3-20. Trunk Utilization screen (1 of 2)
Trunk Utilization
Trunk Traffic Type Port Last 5 Minutes Last 30 Minutes Last Hour
----- ------------- ---- -------------- --------------- ---------
I1 [ Rx and Tx ] 25 90.0% 70.0% 80.0%
26 20.0% 50.0% 100.0%
I2 [ Rx and Tx ] 13 15.0% 45.0% 30.0%
14 60.0% 10.0% 20.0%
I3 [ Rx and Tx ] 19 30.0% 90.0% 80.0%
20 20.0% 10.0% 50.0%
I4 [ Rx and Tx ] 22 85.0% 35.0% 50.0%
23 90.0% 80.0% 70.0%
More...
Press Ctrl-N to display utilization for trunks S1-S4.
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
