Using the Console Interface
893-00992-E
3-37
Figure 3-16. Model 350F-HD Port Configuration screen (2 of 2)
Table 3-13 describes the
Port Configuration screen fields.
Table 3-13. Port Configuration screen fields
Field Description
Port
Indicates the switch port numbers, from 1 to 26, that correspond to the field settings
in that row of the screen (for example, the field settings in row 2 apply to switch
port 2). Note that settings in the All row (bottom row) apply to all 26 switch ports.
Trunk
The read-only data displayed in this column indicates the trunks (
I
1 to
I
4 and S1 to
S4) that correspond to the switch ports specified in the Trunk Members fields of the
Trunk Configuration screen (see “MultiLink Trunk Configuration
” on page 3-39).
(continued)
Port Configuration
Port Trunk Status Link Auto Negotiation Speed Duplex
---- ----- ------------ ---- ---------------- -----------------
13 I2 [ Enabled ] Up [ Enabled ] [ 100Mbs / Full ]
14 I2 [ Enabled ] Up [ Enabled ] [ 100Mbs / Full ]
15 [ Enabled ] Up [ Enabled ] [ 100Mbs / Full ]
16 [ Enabled ] Down [ Disabled ] [ 100Mbs / Half ]
17 S1 [ Enabled ] Up [ Disabled ] [ 100Mbs / Half ]
18 [ Enabled ] Down [ Disabled ] [ 100Mbs / Half ]
19 I3 [ Enabled ] Up [ Disabled ] [ 100Mbs / Half ]
20 I3 [ Enabled ] UP [ Disabled ] [ 100Mbs / Half ]
21 [ Enabled ] Down [ Disabled ] [ 100Mbs / Half ]
22 I4 [ Enabled ] Up [ Enabled ] [ 100Mbs / Full ]
23 I4 [ Enabled ] Up [ Enabled ] [ 100Mbs / Full ]
24 [ Enabled ] Down [ Enabled ] [ 100Mbs / Full ]
25 I1 [ Enabled ] Up [ Disabled ] [ 100Mbs / Full ]
26 I1 [ Enabled ] Up [ Disabled ] [ 100Mbs / Full ]
All [ Enabled ] [ Disabled ] [ 100Mbs / Full ]
Press Ctrl-P to display choices for ports 1-12.
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
To Next Page
