Getting Started
893-00992-E
1-35
Figure 1-23. VLAN Configuration screen example for switch SW1 (2 of 2)
To move a port or trunk to another VLAN, you simply use the arrow keys to
navigate the screen and press the space bar to display choices. Press [Enter] to
select your choice.
For more information about navigating the screens, see “Navigating the CI Menus
and Screens” on page 3-5. For more information about configuring VLANs, see
“VLAN Workgroups
” on page 1-16.
Trunk Configuration Screen for Switch SW2
As shown in Figure 1-17, switch SW2 is set up with two inter-switch trunk
configurations (I1 and I2). Both trunks connect directly to switch SW1.
As in the previous screen examples, to set up an inter-switch trunk configuration
you choose Inter-Switch Trunk Configuration from the MultiLink Trunk
Configuration Menu screen.
Figure 1-24
shows the Inter-Switch Trunk Configuration screen for switch SW2.
VLAN Configuration
Port Trunk V1 V2 V3 V4 V5
---- ----- ----- ----- ----- ----- -----
13 I2 [ X ] [ ] [ ] [ ] [ ]
14 I2 [ X ] [ ] [ ] [ ] [ ]
15 [ X ] [ ] [ ] [ ] [ ]
16 [ X ] [ ] [ ] [ ] [ ]
17 S1 [ X ] [ ] [ ] [ ] [ ]
18 [ X ] [ ] [ ] [ ] [ ]
19 I3 [ X ] [ ] [ ] [ ] [ ]
20 I3 [ X ] [ ] [ ] [ ] [ ]
21 [ X ] [ ] [ ] [ ] [ ]
22 I4 [ X ] [ ] [ ] [ ] [ ]
23 I4 [ X ] [ ] [ ] [ ] [ ]
24 [ X ] [ ] [ ] [ ] [ ]
25 I1 [ X ] [ ] [ ] [ ] [ ]
26 I1 [ X ] [ ] [ ] [ ] [ ]
Press Ctrl-P to display choices for ports 1-12.
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
