Using the BayStack 350 Series 10/100 Autosense Switch
1-34
893-00992-E
Figure 1-22 shows the first VLAN screen for switch SW1. It displays the settings
for switch ports 1 to 16.
To display the second screen for switch ports 13 to 26 (Figure 1-23
), you can press
[Ctrl]+N.
Figure 1-22. VLAN Configuration screen example for switch SW1 (1 of 2)
Note:
All ports in a trunk must be configured in the same VLAN(s) before
they can become trunk members.
VLAN Configuration
Port Trunk V1 V2 V3 V4 V5
---- ----- ----- ----- ----- ----- -----
1 [ X ] [ ] [ ] [ ] [ ]
2 [ X ] [ ] [ ] [ ] [ ]
3 [ X ] [ ] [ ] [ ] [ ]
4 [ X ] [ ] [ ] [ ] [ ]
5 [ X ] [ ] [ ] [ ] [ ]
6 S1 [ X ] [ ] [ ] [ ] [ ]
7 S1 [ X ] [ ] [ ] [ ] [ ]
8 [ X ] [ ] [ ] [ ] [ ]
9 S1 [ X ] [ ] [ ] [ ] [ ]
10 [ X ] [ ] [ ] [ ] [ ]
11 [ X ] [ ] [ ] [ ] [ ]
12 [ X ] [ ] [ ] [ ] [ ]
More...
Press Ctrl-N to display choices for ports 13-26.
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
