Using the BayStack 350 Series 10/100 Autosense Switch
1-46
893-00992-E
The following sections provide example configurations for both monitoring
modes available with the Port Mirroring feature:
• Port-based Mirroring
• Address-based Mirroring
A sample of the Port Mirroring Configuration screen is provided with each of the
examples to support the network configuration example.
Note that in the following examples, the displayed screens do not show all of the
screen prompts that precede some actions. For example, when you configure a
switch for port mirroring or when you modify an existing port mirroring
configuration, the new configuration does not take effect until you respond [Yes]
to the following screen prompt:
For more information about the Port Mirroring feature, see “Port Mirroring
Configuration” on page 3-48.
Port-Based Mirroring Configuration
Figure 1-30
shows an example of a port-based mirroring configuration where port
12 is designated as the monitor port for ports 24 and 25 of switch SW1. Although
this example shows ports 24 and 25 monitored by the monitor port (port 12), any
of the trunk members of I1 and I2 can also be monitored.
Figure 1-31
shows the Port Mirroring Configuration screen setup for this example.
Note:
Trunks cannot be monitored and trunk members cannot be configured
as monitor ports (see “MultiLink Trunking Configuration Rules
” on
page 1-41
).
Is your port mirroring configuration complete? [ Yes ]
