Using the BayStack 350 Series 10/100 Autosense Switch
1-48
893-00992-E
As shown in the Port Mirroring Configuration screen example (Figure 1-31), a
user has designated port 12 as the Monitor Port for ports 24 and 25 in switch SW1.
The Monitoring Mode field [ - > Port X or Port Y - > ] indicates that all traffic
received by port X or all traffic transmitted by port Y is currently being monitored
by the StackProbe attached to Monitor Port 12.
The screen data displayed at the bottom of the screen shows the currently active
port mirroring configuration.
Figure 1-31. Port Mirroring port-based screen example
See “Port Mirroring Configuration” on page 3-48 for a full description of the Port
Mirroring Configuration screen fields.
Port Mirroring Configuration
Monitoring Mode: [ -> Port X or Port Y -> ]
Monitor Port: [ 12 ]
Port X: [ 25 ]
Port Y: [ 24 ]
Address A: [ 00-00-00-00-00-00 ]
Address B: [ 00-00-00-00-00-00 ]
Port mirroring configuration has taken effect.
Currently Active Port Mirroring Configuration
---------------------------------------------
Monitoring Mode: -> Port X or Port Y -> Monitor Port: 12
Port X: 25 Port Y: 24
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
