Using the BayStack 350 Series 10/100 Autosense Switch
3-46
893-00992-E
Figure 3-21. Trunk Utilization screen (2 of 2)
Table 3-17 describes the Trunk Utilization screen fields.
Table 3-17. Trunk Utilization screen fields
Field Description
Trunk
Column header for the read-only fields in this screen. The read-only data displayed in
this column indicates the trunks (
I
1 to
I
4 or S1 to S4) that correspond to the switch
ports specified in the Port field.
Traffic Type
Allows you to choose the traffic type to be monitored for percent of bandwidth
utilization (see Range).
Default Rx and Tx
Range Rx and Tx, Rx, Tx
Port
This field lists the trunk member ports that correspond to the trunk specified in the
Trunk column.
(continued)
Trunk Utilization
Trunk Traffic Type Port Last 5 Minutes Last 30 Minutes Last Hour
----- ------------- ---- -------------- --------------- ---------
S1 [ Rx and Tx ] 6 40.0% 20.0% 55.0%
7 20.0% 70.0% 10.0%
9 25.0% 15.0% 50.0%
17 65.0% 50.0% 80.0%
S2 [ Rx and Tx ]
S3 [ Rx and Tx ]
S4 [ Rx and Tx ]
Press Ctrl-P to display utilization for trunks I1-I4.
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
