Figure 1-21. Inter-Switch Trunk Configuration screen example
The Inter-Switch Trunk Configuration screen for switch SW1 is configured as
follows:
• Trunk (read only) indicates the trunks (I1 through I4 for this switch) that
correspond to the switch ports specified in the Trunk Members fields.
• Trunk Members indicates the ports that can be configured, in each row, to
create the corresponding trunk:
-- Ports 25 and 26 are assigned as trunk members of trunk I1.
-- Ports 13 and 14 are assigned as trunk members of trunk I2.
-- Ports 19 and 20 are assigned as trunk members of trunk I3.
-- Ports 22 and 23 are assigned as trunk members of trunk I4.
• STP indicates the spanning tree participation setting for each of the trunks:
In this example, trunks I1 to I4 are enabled for spanning tree participation.
Inter-Switch Trunk Configuration
Trunk Trunk Members STP Trunk Mode Trunk Status
----- ---------------------------- ------------ --------------- ------------
I1 [ 25 ][ 26 ][ ][ ] [ Enabled ] [ Enhanced ] [ Enabled ]
I2 [ 13 ][ 14 ][ ][ ] [ Enabled ] [ Enhanced ] [ Enabled ]
I3 [ 19 ][ 20 ] [ Enabled ] [ Enhanced ] [ Enabled ]
I4 [ 22 ][ 23 ] [ Enabled ] [ Enhanced ] [ Enabled ]
Valid inter-switch trunk configurations are:
1 or 2 trunks of up to 4 links each
Up to 4 trunks of 2 links each
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
