NSD VARILIMIT VS-12PB User Manual

● APPX-2 ●
The initial settings shown below are required in order to use special functions. If such functions are not being used,
these settings should be left at their default (factory set) values.
Init. No. Item Description Setting Data
Setting
value
80-1
Multi-drop
communication
selection
Designate whether or not multidrop
communication format (RS-485) is to be used
between VS-12PB units.
NO:
YES:
0
1
80-6
Slave No. selection Specifies the unit No. communication with
multiple units. Set to “0” if connected to the host
controller.
0 ~ 31
1
81
Communication
specifications
selection
Selects the communication specifications in
systems where communication is to occur with a
host controller. (Select “3: VS-T12 (VS-T12B)” if
connected to the positioning setting display unit.
See Note 1.)
NO:
RS-232C:
RS-422:
VS-T12 (VS-T12B):
0
1
2
3
82
Permissible
communication
setting range
Selects the setting
change range in
systems where
settings can be
changed from a host
controller.
* Settings changed in
this manner are lost
at power OFF.
82-1 Initial settings NO
1
82-2 Parameter 1
(PRMTR:60 ~ 75)
NO:
YES:
1
2
82-3 Parameter 2
(PRMTR:40 ~ 55)
NO:
YES:
1
2
82-4 Program NO:
YES:
1
2
82-5
Command
communication
Designates whether or not communication
control is possible.
NO:
YES:
1
2
83
Communication format
selection
Designates the format for communication
with Host Controller.
Personal computer:
AJ71C24-S8:
VS-T12 (VS-T12B):
0
1
2
85
Brake monitor Designates whether or not an operation error
will be detected based on the braking count.
NO:
YES:
0
1
86
Braking count display
& 0 set
The braking count is displayed. Reset is
possible by entering password as follows:
0
The actual braking count value
is the displayed value × 1000.
87
Max. braking count
setting
Sets the maximum number of brake operations.
Setting range
[1 ~ 999999]
999999
The actual braking count value
is the displayed value × 1000.
89
Downloading enabled
selection
Designates whether or not down loading by
communication format is possible.
Note
“1” must be designated for each downloading
operation.
NO:
YES:
0
1
Note 1
When “3: VS-T12 (VS-T12B)” is selected, the setting data at initial setting Nos. 80-1, 82, 83, and at parameter No.40
become invalid, and the VS-T12 (VS-T12B) is enable in the controller.
