(3) Current position value detection for axis 2
I/O
Address
Write Name
Data
format
Initial
value
Data range Description
Parameter
No.
16448 R Current position value (scaling binary) DINT
-99999~
999999
16449
R
Current position value (sensor binary)
UDINT
0~131071
16450 R Speed output DINT
-32768~
32767
16451 R
Current position in hold status
(scaling binary)
DINT
-99999~
999999
16452 R
Current position in hold status
(sensor binary)
UDINT 0~131071
16453 W Current position preset input 1 DINT 0
-99999~
999999
16454 W Current position preset input 2 DINT 0
-99999~
999999
16455 W
Current position preset input
disabled setting
BYTE 0
16456 IW
Sensor type and
rotational direction
USINT 0
0
MRE-32SP062 CW
90
1
MRE-32SP062 CCW
2
MRE-G
＿
SP062 CW
3
MRE-G
＿
SP062 CCW
99
Not used
16457 IW Decimal point position USINT 0
0
0
91
1
0.0
2
0.00
3
0.000
4
0.0000
5
0.00000
16458 IW Scale length UDINT 131072
1000~
999999
92
16459 IW Minimum current position value DINT 0
-99999~
999999
93
16460 IW Current position value DINT 65536
-99999~
999999
94
16461 PW
Permissible current position
change amount
UDINT 999999 0~999999
68
16462
PW
Permissible correction amount
UDINT
999999
0~999999
69
16463 PW Current position preset function USINT 0
0
Disabled
70
1
Parameter format
2
Buffer memory format
3
Sequence format
16464 PW Current position preset value 1 in FWD DINT 0
-99999~
999999
71
16465 PW Current position preset value 1 in RVS DINT 0
-99999~
999999
72
16466 PW Current position preset value 2 in FWD DINT 0
-99999~
999999
73
16467 PW Current position preset value 2 in RVS DINT 0
-99999~
999999
74
16468 PW Speed gate time USINT 0
0
8ms
75
1
16ms
2
32ms
3
64ms
4
128ms
5
Rotational speed (r/min)
16469 PW Speed gate sampling time USINT
0
Gate time
76
1
Half of gate time
2
Quater of gate time
