5.2.9 Error history
Inthesettingmode(08-9703),thelatesttwentygroupsoferrordatawillbedisplayed.
Display example
EA10 99999999 06 04 14 17 57 32 064 064 2362_1000_0000_0
_XXXXXXXXXX
Error code Total counter YYMMDDHHMMSS MMM NNN ABCD_EFHI_JLOP_Q
_R
4 digits 8 digits 12digits(Yearisindicated
with its last two digits.)
3 digits 3 digits 23 digits
A Paper source
0:Notselected  1:MPT  2:LCF  3:1stTray 4:2ndTray
5: 3rd Tray 6: 4th Tray 7: Unused 8: Unused
B Paper size code
0:A5/ST 1:A5-R 2:ST-R 3:LT 4:A4 5:B5-R 6:LT-R 7:A4-R 8:OTHER/UNIV
9:B5 A:FOLIO/COMP B:LG C:B4 D:LD E:A3 F:13"LG G:13.5inch-R
H:A6-R I:Postcard J:8.5"SQ K:A3-wide L:LDwide
M:8K N:16K-R O:16K  P:Com9-R Q:Envelope(DL)
R:Envelope(Monarch) S:Envelope(Cho-3) T:Envelope(You-4,C5-R)
U:Exective-R V:IndexCard-R Z:Notselected
C Sort mode/staple mode
0: Non-sort/Non-staple 1: Group 2: Sort 7: Front staple
8: Double staple 9: Rear staple A: Saddle stitch
D ADF mode
0:Unused 1:AUTOFEED(SADF) 2:STACKFEED
E APS/AMS mode
0: Not selected 1: APS 2: AMS
F Duplex mode
0: Not selected 1: Book 2: Double-sided/Single-sided 4: Double-sided/Duplex copying
8: Single-sided/Duplex copying
G Unused
H Image shift
0:Unused 1:Book 2:Left 3:Right 4:Top 5:Bottom 6:Book+Top
7:Book+Bottom 8:Left+Top 9:Left+Bottom A:Right+Top B:Right+Bottom
I Editing
0: Unused 1: Masking 2: Trimming 3: Mirror image 4: Unused
5: NEG/POS
J Edge erase/Dual-page
0: Unused 1: Edge erase 2: Dual-page 3: Edge erase & Dual-page
K Unused
L Function
0:Unused 1:Copying 2:FAX/InternetFAXtransmission
3:FAX/InternetFAX/E-mailreceptionprinting 4:Unused
5:Printing/Listprint  6:Scan/E-mailtransmission
MMM Primary scanning reproduction ratio (Display in hexadecimal)
(Mx256)+(Mx16)+M
NNN Secondary scanning reproduction ratio (Display in hexadecimal)
(Nx256)+(Nx16)+N
To Next Page
