45584901TH Re
v
.1
2-4 /
Oki Data CONFIDENTIAL
2.1.4
Caster Stand
(1)
Press the [P
ow
er] button on the control panel to shut it do
wn.
(2)
T
urnthemainpowers
witchoftheequipmentoff
.
(3)
Disconnect the po
wer cab
le.
(4)
Release the loc
k.
Fig.
2-8
(5)
Remo
v
e 2 screws and tak
e off 2 fixing brac
k
ets.
Fig.
2-9
(6)
Lifttheequipmentupandremo
v
ethecaster
.
Fig.
2-10
