4.3.18 Density adjustment of graphic lines (1200 dpi)
Thisadjustmentisavailableregardlessofwhether“DistinguishThinLines”oftheprinterdriveris
selected or not.
<Adjustment Mode (05)>
Color mode Code Remarks
Color/Black 8242-0 The density of the line in Black in the line density range specified by
"05-8243-0" or "05-8243-1" can be adjusted.
Thelargerthevalueis,thedarkerthelinedensitybecomes.
Acceptable value: 0 to 5 (Default: 3)
8242-1 ThedensityofthelineinYellow,Magenta,Cyan,andBlackinthe
line density range specified by "05-8243-2" or "05-8243-3" can be
adjusted.
Thelargerthevalueis,thedarkerthelinedensitybecomes.
Acceptable value: 0 to 5 (Default: 1)
Color mode Code Remarks
Color/Black 8243-0 The effective range (lower limit) of the density
adjustment for the line in Black can be set.
Acceptable value: 0 to 255 (Default: 1)
The density range
selected in the
upper and lower
limit is adjusted
with 05-8242-0.
8243-1 The effective range (upper limit) of the density
adjustment for the line in Black can be set.
Acceptable value: 0 to 255 (Default: 200)
8243-2 The effective range (lower limit) of the density
adjustmentforthelineinYellow,Magenta,
Cyan,andBlackcanbeset.
Acceptable value: 0 to 255 (Default: 1)
The density range
selected in the
upper and lower
limit is adjusted
with 05-8242-1.
8243-3 The effective range (upper limit) of the density
adjustmentforthelineinYellow,Magenta,
Cyan,andBlackcanbeset.
Acceptable value: 0 to 255 (Default: 255)
Notes:
Be sure to set the values of the upper and lower limit properly so that they are not set in
reverse.Thelinedensityadjustmentcodeswithblack(8242-0,8243-0and8243-1)arein
common for both the color and black modes.
<Procedure>
The procedure is the same as that of

P.4-9“4.3.2Gammabalanceadjustment(BlackMode)”.
