3.2 Service UI
3.2.1 Overview
The following self-diagnostic modes can be used with Service UI on the touch panel of the
control panel.
• 05ADJUSTMENTMODE
• 08SETTINGMODE
• FAXLISTPRINTMODE
• CHARTPRINTMODE
3.2.2 Loginprocedure
[1] In the normal mode
(1) Turn the power ON.
(2) Press the [SETTING] button.
(3) Withthe[SETTING]menudisplayed,entertheServiceModepasswordprovidedduring
product training.
Fig. 3-2
(4) EntertheusernameandpasswordontheSERVICETECHNICIANPASSWORDscreen,
thenpress[OK].Theyaresetbydefaultasfollows:
User Name Service
Password None
Fig. 3-3
 TheSERVICEMODEscreenisdisplayed.
