Oki MC770 Maintenance Manual

45584901TH Rev.1
5-39 /
Oki Data CONFIDENTIAL
[EAF8] Stacker motor position detection error
Classification Error content
Finisher related service call Stacker motor position detection error
Check item Measures
Stack home position sensor • Sensorcheck(S9)
• Connectorcheck(P7-11)
• Harnesscheck
Stacker motor • Motorcheck(M8)
• Connectorcheck(P14-3)
• Harnesscheck
Finisher control PC board • Boardcheck
• Connectorcheck(J7,J14)
• Harnesscheck
Parts to be replaced Remark
Stack home position sensor
Stacker motor
Finisher control PC board
[ED15] Paddle HP abnormality
Classification Error content
Finisher related service call Paddle HP abnormality
Check item Measures
Paddle home position sensor • Sensorcheck(S3)
• Connectorcheck(P8-4)
• Harnesscheck
Paddle motor • Motorcheck(M3)
• Connectorcheck(P5-4)
• Harnesscheck
Finisher control PC board • Boardcheck
• Connectorcheck(J5,J8)
• Harnesscheck
Parts to be replaced Remark
Paddle home position sensor
Paddle motor
Finisher control PC board
