45584901TH Rev.1
3-13 /
Oki Data CONFIDENTIAL
Code Types of test pattern Remarks
91 Printer gamma correction table confirmation pattern
(Thin paper/PS/600dpi)
Refer to 4.3.1Automatic gamma adjustment
200 Copier gamma adjustment pattern
(Color & black integrated / Plain paper)
Refer to 4.2.1Automatic gamma adjustment
201 Copier gamma confirmation pattern
(Color / Plain paper)
Refer to 4.2.1Automatic gamma adjustment
204 Copier gamma adjustment pattern
(Color & black integrated / Thick paper 5)
Refer to 4.2.1Automatic gamma adjustment
205 Copier gamma confirmation pattern
(Color / Thick paper 5)
Refer to 4.2.1Automatic gamma adjustment
206 Copier gamma adjustment pattern
(Color & black integrated / Thick paper 1)
Refer to 4.2.1Automatic gamma adjustment
207 Copier gamma confirmation pattern
(Color / Thick paper 1)
Refer to 4.2.1Automatic gamma adjustment
208 Copier gamma adjustment pattern
(Color & black integrated / Thick paper 2)
Refer to 4.2.1Automatic gamma adjustment
209 Copier gamma confirmation pattern
(Color / Thick paper 2)
Refer to 4.2.1Automatic gamma adjustment
210 Copier gamma adjustment pattern
(Color & black integrated / Thick paper 3)
Refer to 4.2.1Automatic gamma adjustment
211 Copier gamma confirmation pattern
(Color / Thick paper 3)
Refer to 4.2.1Automatic gamma adjustment
212 Copier gamma adjustment pattern
(Color & black integrated / Thick paper 4)
Refer to 4.2.1Automatic gamma adjustment
213 Copier gamma confirmation pattern
(Color / Thick paper 4)
Refer to 4.2.1Automatic gamma adjustment
216 Copier gamma adjustment pattern
(Color & black integrated / Special paper 4)
Refer to 4.2.1Automatic gamma adjustment
217 Copier gamma confirmation pattern
(Color / Special paper 4)
Refer to 4.2.1Automatic gamma adjustment
218 Copier gamma adjustment pattern
(Color & black integrated / Special paper 3)
Refer to 4.2.1Automatic gamma adjustment
219 Copier gamma confirmation pattern
(Color / Special paper 3)
Refer to 4.2.1Automatic gamma adjustment
220 Copier gamma adjustment pattern
(Color & black integrated / Thin paper)
Refer to 4.2.1Automatic gamma adjustment
221 Copier gamma confirmation pattern
(Color / Thin paper)
Refer to 4.2.1Automatic gamma adjustment
230 Copier gamma adjustment pattern
(Plain paper / PS / 1200dpi)
Refer to 4.3.1Automatic gamma adjustment
231 Copier gamma confirmation pattern
(Plain paper / PS / 1200dpi)
Refer to 4.3.1Automatic gamma adjustment
234 Copier gamma adjustment pattern
(Thick paper 5 / PS / 1200dpi)
Refer to 4.3.1Automatic gamma adjustment
235 Copier gamma confirmation pattern
(Thick paper 5 / PS / 1200dpi)
Refer to 4.3.1Automatic gamma adjustment
236 Copier gamma adjustment pattern
(Thick paper 1 / PS / 1200dpi)
Refer to 4.3.1Automatic gamma adjustment
237 Copier gamma confirmation pattern
(Thick paper 1 / PS / 1200dpi)
Refer to 4.3.1Automatic gamma adjustment
