95
Communication Menu Configuration
26
26.5 AddRES Enter ADDRESS SELECTION SUBMENU
Press ‘RESET/ENTER’ 60) Display shows "StOREd" stored message momentarily and then
advances to the "AddRES” Address selection submenu.
• This menu is applicable to the RS-485 Option only to designate different
address for each device or controller in the Multi-point Serial
Communication network that allows hosting device to recognize and
communicate properly as labeling or naming purposes.
Press ‘RESET/ENTER’ 61) Display flashes "001" Address Value 1 as default.
Press ‘䊱/MAX’ & ‘
䊳
/MIN’ 62) To modify and select Address Value for your choice of setting. This
controller supports value within 000 – 199.
26.6. SERCNt Enter SERIAL COUNT SUBMENU
Press ‘RESET/ENTER’ 63) Display shows "StOREd" stored message momentarily and then
advances to the "SERCNt" Serial Count submenu.
• Serial Count menu is used to program the number of readings the meter
just take (programmable from "00001" to "59999") between
transmissions of data via the Serial Communication Option Board.
Caution: For proper communication, do not set Serial Count Value at
"00000".
Press ‘RESET/ENTER’ 64) Display flashes "00001" as default Serial Count value.
Press ‘䊱/MAX’ & ‘
䊳
/MIN’ 65) To modify and select the desired value of Serial Count (number of
readings) between data transmissions.
Press ‘RESET/ENTER’ 66) Display shows "StOREd" stored message momentarily and then
advances to the "COLOR" LED Color Select submenu.
To Next Page
