5.1 CONDITIONS REQUIRING DISASSEMBLY
You may need to remove the sleeve or open the unit for several reasons:
1. To inspect the rating label on the case (Section 5.2.1).
2. To install optional output board(s) (Section 5.2.2).
3. To mount the unit in a panel (Section 5.2.4).
5.2 ASSEMBLY/DISASSEMBLY
OPENING THE UNIT
Your unit is fully assembled, but not wired. See Section 7 for wiring connection for power and sensor
inputs. In most cases, if you have ordered optional boards with the meter, these boards will already be
installed.
You will need to remove only the rear cover to complete wiring, but you will have to open the meter to
do one or more of the following:
a. Install optional boards. See Section 5.2.2.
b.
Access jumpers on the Main and optional boards. See Section 5.2.3.
WARNING!: You must disconnect and turn-off the power and connector signals before
accessing the unit and installing optional boards. Failure to do so may result in injury!
